12.3inch LP123QP1-SPA2 3000X2000 LCD Screen with Type C HD-MI Controller Board

Model NO.
K002633 VS-MST9U11Q1+LP123QP1-SPA2
Delivery:
EXW or FOB ShenZhen
Minimum order quantity:
1
Country of Origin:
CHINA
Stock Time:
3-7days Days
Quantity:
  • Products Status:Stock
  • Resolution:3000X2000
  • Brightness:450 cd/m²
  • Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
  • Backlight:WLED
  • Interface:30 pins LVDS (2 ch, 8-bit) , Connector
  • Size:12.3inch
  • LCD Part No:LP123QP1-SPA2
  • Product Name:TFT Module Screen
  • Type:TFT
  • Place of Origin:CN;GUA
  • Display Size:12.3inch
  • Supplier Type:Manufacture
  • Model Number:K002633 VS-MST9U11Q1+LP123QP1-SPA2
  • Brand Name:VS
Products Show
Product Description
LCD Screen:
12.3"LP123QP1-SPA2 3000X2000 LCD Screen:
Details:
Display Mode AAS, Normally Black, Transmissive
Resolution 3000(RGB)×2000 293PPI
Outline Size 265.35(H)×183.49(V) ×4.3(D) mm)
Display Area 259.65(H)×173.1(V) mm)
Brightness 450 cd/m² (Typ.)
Contrast Ratio 1200:1 (Typ.) (TM)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10) [Left / Right / Up / Down]
Signal Interface eDP (4 Lanes) , 40 pins Connector
Backlight WLED
Input Voltage 3.3V (Typ.)
LCD Board:
LCD Controller Board
Details:
Type C HDMI Board For 4 Lane eDP Support Max 4096x2160 60Hz LCD Screen
Input Power Adapter: PD 5V dc Type C 18W
Come In Standby Model When Not Input Signal
Standby Model <1.2W
HDR: Support
Video Input
HDMI (HDMI 2.0 max 3840x2160 60Hz Support HDCP2.2)
Type-C (Data Transmission Image Display 5V Max 3A output)
Audio Output: Earphone
OSD: Brightness Contrast VOL+ VOL- Language And So On
Language: English French German Spanish Italian And So On
Board Size: 62.0mm x 135mm x 5mm
Packing list:
1× HDMI TYPE-C LCD Controller Board MST9U11Q1
1× 12.3inch LP123QP1-SPA2 3000X2000 LCD Screen
1× Converter Board
1× Signal Cable
1× Keyboard
