LCD Controller Board VS-TY2662-V1:
VS-TY2662-V1 is a LCD control board, it supports between 7 and 22 inch LCD panel with single /dual LVDS interface. This board support VGA+2CVBS input and support reversing function
Size: 90.58mm(L)*65.6mm(W)*12mm(H)
Input Power Adapter: 12Vdc More than 2A
OSD LANGUAGE: English, French, German, Italian, Spanish, Portuguese, Korean (optional) And So On
KEY FUNCTION: Auto, Menu, Vol-, Vol+, Power
Operation temperature: 0~40°C.
standby< 1W
Panel Interface: 50PIN TTL/6Bit 8it Dual/Single LVDS interface
Panel Resolution: Up to 1920x1080
GENERAL PRECAUTIONS:
Don’t wire in the board to power supply before panel is correctly connected
7inch 1024x600 IPS LCD Panel HV070WS1-105:
Composition: LCM
Size:7.0”
Resolution: 1024x600
Outline Dimension:163.6x102.9x2.47mm
Active Area:153.6x102.9mm
Signal Interface: LVDS
Brightness: 400 cd/m²
Operating Temperature: -40~70℃
Flat Rectangle Display: 17:10
Contrast Ratio:800:1
Viewing Angle:85/85/85/85(Typ.)(CR≥10)
