Model NO.
K000617 VS-TY50-V2+AT090TN10+Remote
Quantity:
  • LCD Controller Board:
    HDMI LCD Board Work for 50Pin TTL LCD Screen
    Input Power Adapter:5Vdc More than 2A.
    Come In Standby Model When Not Input Signal
    Standby Model <1W
    Video Input: HDMI
    OSD: Brightness Contrast Auto Language And So On
    Language: English French German Spanish Italian And So On
    Board Size:70mm x 50mm x 8mm
  • 9"AT090TN10 800X480 LCD Screen:
    Display Mode TN, Normally White, Transmissive
    Resolution 800RGB)×480
    Outline Size 211.1× 126.5×5.7 (H×V×D)
    Display Area 198 × 111.7 (H×V)
    Brightness 450 cd/m² (Typ.)
    Contrast Ratio 500:1 (Typ.) (TM)
    Viewing Angle 70/70/50/70 (Typ.)(CR≥10) [Left / Right / Up / Down]
    Signal Interface Parallel RGB (1 ch, 8-bit) , 50 pins , FPC
    Backlight WLED
    Input Voltage 3.3V (Typ.)
  • Packing list :
    1× HDMI LCD Controller Board VS-TY50-V2
    1× 9inch AT090TN10 800X480 LCD
    1× Power Supply Cable
    1× Keyboard With Cable
    1× Remote Control(Battery Not included)
