14inch NV140FHM-N44 1920X1080 IPS LCD Screen ​​​​​​​
14inch NV140FHM-N44 1920X1080 IPS LCD Screen ​​​​​​​
14inch NV140FHM-N44 1920X1080 IPS LCD Screen ​​​​​​​
14inch NV140FHM-N44 1920X1080 IPS LCD Screen ​​​​​​​
14inch NV140FHM-N44 1920X1080 IPS LCD Screen ​​​​​​​

14inch NV140FHM-N44 1920X1080 IPS LCD Screen ​​​​​​​

Model NO.
A000178-EDP-NV140FHM-N44 1920x1080
Quantity:
14"LCD Screen NV140FHM-N44:
Display Mode N, ADS, Normally Black, Transmissive
Resolution 1920RGB)×1080
Outline Size 320.4 × 205.1 × 3 (H×V×D)
Display Area 309.31 × 173.99 (H×V)
Brightness 300 cd/m² (Typ.)
Contrast Ratio 800:1 (Typ.) (TM)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10) [Left / Right / Up / Down]
Signal Interface eDP (2 Lanes) , Connector , 30 pins

BacklightWLED
Input Voltage  3.3V (Typ.)

Packing list :
1×14inch NV140FHM-N44 1920X1080IPSLCD Screen
