LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen
LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen

LCD Controller Board VST Y2662 V1, 7inch 800x480 resolution 60pin TFT LCD Screen

Model NO.
K001055 VS-TY2662-V1+HSD070IDW1
Minimum order quantity:
1 piece
Supply Ability:
100000.0 piece / Day
Country of Origin:
FOB SHENZHEN
Quantity:
  • LCD Controller Board:
    HDMI VGA 2AV LCD Board Work for LVDS Interface LCD Screen
    50Pin TTL Connector for 7inch~10.1inch LCD Screen
    Input Power Adapter:12Vdc More than 2A.
    Come In Standby Model When Not Input Signal
    Standby Model <1W
    Video Input: HDMI VGA AV1 AV2
    Reversing: Support Automatically Switch To AV2 When Connector ACC to 12V
    OSD: Brightness Contrast Auto Language And So On
    Language: English French German Spanish Italian And So On
    Board Size:91mm x 66mm x 12mm
  • 7"HSD070IDW1 800X480 LCD Screen:
    Display Mode TN, Normally White, Transmissive
    Resolution 800RGB)×480
    Outline Size 165.2 ×104×5.4 (H×V×D)
    Display Area 153.6 × 86.64 (H×V)
    Brightness 200 cd/m² (Typ.)
    Contrast Ratio 500:1 (Typ.) (TM)
    Viewing Angle 70/70/50/60 (Typ.)(CR≥10) [Left / Right / Up / Down]
    Signal Interface Parallel RGB (1 ch, 8-bit) , 50 pins , FPC
    Backlight WLED
    Input Voltage 3.3V (Typ.)
  • Packing list :
    1× HDMI VGA+2AV LCD Controller Board VS-TY2662-V1
    1× 7inch HSD070IDW1 800X480 LCD Screen
    1× LVDS Cable
    1× Tcon Board
    1× Keyboard With Cable
    1× Remote Control(Battery Not included)
